Stenner Pump Econ FP E20PHF

The Econ FP peristaltic metering pump has all the features found in a microprocessor controlled system at a fraction of the cost.

This new pump is feature rich, simple in design and very easy to setup. Features:

• Water Meter Control:

  • The pump has a built in pump control module that accepts pulsed input from a water meter with a mechanical read switch.

  • For each pulse received the pump will turn on from 0.1 to 1 second or 0.5 to 5, 1 to 10, 2 to 20 or 6 to 60 seconds per pulse

• Flow Switch Control:

  • When connected to a mechanical flow switch the pump will accept a contact closure input to start and stop the pump. Speed is controlled by pre-programming the pump to a selected speed from 10% to 100%. Alternatively you can use any dry contact as an input for start/stop control, like a relay or external on/off switch located in a remote location.

• 24 Volt AC Input Control:

  • When the pump sees a 24 VAC input signal it will run from 10% to 100% of it's rated speed. This works just like the flow switch input control. This start/stop signal voltage is found on many water softeners and other types of equipment.

• Easy Tube Replacement:

  • Slide cover up to access tube and rollers.

  • Pull out old tube, inspect rollers, clean housing

  • Install a new tube, replace cover and lock and

  • that's it. Easy tube replacements.

• Specifications:

  • Pressure: 80 PSI

  • Voltage: 120 VAC

  • Maximum Outputs: 4.5 GPD, 16 GPD, 30 GPD

  • Power Cord: 6' or 10' optional

  • Weight: 4 lbs

  • Dimensions: 5.3" L x 3.6" W x 5.8 H

  • Agency Approvals: UL & cUL Listed NSF 61 & 372 listed for USA and Canada
